Electric Luggage Tractor

● Zoo yoog raws;
● Lub tshuab traction muaj qhov pom tau zoo, thiab tus neeg tsav tsheb tuaj yeem ncaj qha saib lub rooj zaum traction thaum zaum ntawm lub rooj zaum;
● Cov qauv ntawm cov khoom siv kis tau tus mob yog optimized los txo qhov kis tau tus mob torque poob thiab suab nrov, thiab ua rau kom lub neej ntawm cov kis tau tus mob;

Xa kev nug

Khoom Taw qhia

Qauv				EPQ 100	PAB 120	PAB 120	PAB 150	PEBQ 200	SIB 250	SIB 300
Hom kev ua haujlwm				Zaum Hom					Zaum Hom	Zaum Hom
Hwj chim				Lead Acid	Lead Acid	Lead Acid	Lead Acid	lithium hlau phosphate roj teeb	Lithium roj teeb	Lithium roj teeb
Yam ntxwv	Qhov siab tshaj plaws nuv traction		KN	8.5	11.3	11.3	12.3	18.5	22.5	25.1
	Load traction		KN	2.2	2.3	2.56	3.8	8	12	15
	Max towing hnyav	Trailer	Kg	10000	12000	12000	15000	20000	25000	30000
	Maximum mus txawv tebchaws	ua ntej Unladen/Laden	Km/h	12/6.0	10.0/5	16.0/8	16.0/8	25	25	25
	Maximum mus txawv tebchaws	thim rov qab	Km/h	6	6	10	10	10	10	8
	Yam tsawg kawg nkaus tig radius		mm	2890	2890	2890	2890	2800	2800	2800
	Max. gradeability, Unladen		%	20	25	25	25	30	30	30
	Qhov siab tshaj plaws nres nres	Tsis muaj kab mop nuv	m	2.8	2.8	2.8	2.8	5.7	5.7	5.7
	Qhov siab tshaj plaws nres nres	Towing ntsuas qhov hnyav	m	2.3	2.3	2.3	2.3	4.7	4.7	4.7
Qhov ntev	Zuag qhia tag nrho ntev (Traction nuv)		l1 (mm)	2460	2460	2460	2460	3085	3085	3110
	Dav dav		b1 (mm)	1150	1150	1150	1150	1403	1403	1440
	Zuag qhia tag nrho qhov siab (Cab, tswb teeb)		h1 (mm)	2111	2111	2111	2111	2270	2270	2175
	Pem Hauv Ntej Log Base		b2 (mm)	1000	1000	1000	1000	1220	1220	1240
	Tsheb log puag		b3 (mm)	985	985	985	985	1190	1190	1250
	Log puag		Y (mm)	1450	1450	1450	1451	1600	1600	1650
	Towing qhov siab ntawm towing peg up/down		h3 (mm)	350/450	350/450	350/450	350/450	310/400	310/400	310/400
	Min. av clearance		m2 (mm)	100	100	100	100	165	165	180
Hom	Lub log	Pem hauv ntej Log		5.00-8	5.00-8	5.00-8	5.00-8	6. 50-10PR	6. 50-10PR	6. 50-10PR
Hom	Lub log	Tsheb log		6.00-9	6.00-9	6.00-9	6.00-9	7. 00-15PR	7. 00-15PR	7. 00-15PR
Qhov hnyav	Qhov hnyav (Cab)		Kg	1950	2050	2130	2230	5310	5310	5310
	Axle load (Unladen, Cab)	Pem hauv ntej qag							1820	1820
	Axle load (Unladen, Cab)	rear qag							3490	3490
Kev sib kis	Rated ceev		rpm ua					2065	2065	2065
	Rated zog (Tsav Tsheb)		kW	8	9	9	12	18	23	25
	Rated Torque		N·m					106.5	106.5	106.5
	Rated zog (Steering)		kW					2.5	2.5	2.5
	Kev sib kis iav piv							23.5	23.5	23.5
Roj teeb	Voltage / Muaj peev xwm		V/Ah	48V/400Ah/450/480/540/585/630	48V / 450Ah	80V / 300Ah	80V / 375Ah	80V / 600Ah	80V / 600Ah	80V / 600Ah
Charger	Voltage / Tam sim no		V/A				80V/40A		80V/80A	80V/80A
Steering	Hydraulic zog Steering			EPS				HPS
Nres	Hom							Lub tshuab nqus tsev pab braking system
	Kev pabcuam nres			Tsheb log nruas nres				Tsheb log nruas thiab pem hauv ntej log clamp nres
	Chaw nres tsheb nres			Mechanical rear log braking				Mechanical rear log braking
Cov ntaub ntawv tsuas yog siv rau kev siv xwb, thiab cov ntsiab lus yuav tsum raug rau lub tsheb tiag tiag.

KHOOM NTA

● Zoo yoog raws;

● Lub tshuab traction muaj qhov pom tau zoo, thiab tus neeg tsav tsheb tuaj yeem ncaj qha saib lub rooj zaum traction thaum zaum ntawm lub rooj zaum;

● Cov qauv ntawm cov khoom siv kis tau tus mob yog optimized los txo qhov kis tau tus mob torque poob thiab suab nrov, thiab ua rau kom lub neej ntawm cov kis tau tus mob;

● Hydraulic tsheb laij teb txheem fais fab faib hydraulic commutation thiab ntse hloov;

● Lub tank roj tau muab tso rau ntawm sab, uas ua rau nws yooj yim rau ntxiv thiab tso roj.
