Ib leeg Mast Aluminium Alloy Nqa Platform
Tus kheej-tsim ib qho tseem ceeb hauv cov zawv zawg thaiv yog siv ntawm txhua lub mast, kom qhov sib txawv ntawm cov masts me me, thiab nws khiav thaum nqa ntau ruaj khov thiab txhim khu kev qha, zoo dua li cov qauv kev ywj pheej ntawm kev txhawb nqa;
|
Tib Mast ALUMINIUM ALLOY LIFT PLATFORM |
||||||
|
Qauv |
GTWY1-5 |
GTWY1-6 |
GTWY1-8 |
GTWY1-9 |
GTWY1-10 |
GTWY1-12 |
|
Platform |
||||||
|
Max. Ua haujlwm siab |
6.7m |
8.2m |
9.8m |
11.2m |
12.4m |
14m |
|
Max. Platform Qhov siab |
4.7m |
6.2m |
7.8m |
9.2m |
10.4m |
12m |
|
Chaw thau khoom muaj peev xwm |
150 kg |
150 kg |
150 kg |
150 kg |
136kg ua |
120 kg |
|
Cov neeg nyob |
1 |
1 |
1 |
1 |
1 |
1 |
|
Platform Dimension |
0.67m x 0.66m |
0.67m x 0.66m |
0.67m x 0.66m |
0.67m x 0.66m |
0.67m x 0.66m |
0.67m x 0.66m |
|
Zuag qhia tag nrho Dimension |
||||||
|
Tag Nrho Qhov Siab |
1.99m |
1.99m |
1.99m |
1.99m |
1.99m |
2.68m |
|
Dav dav |
0.74m |
0.74m |
0.74m |
0.74m |
0.74m |
0.81m |
|
Zuag qhia tag nrho ntev |
1.24m |
1.24m |
1.36m |
1.4m |
1.42m |
1.46m |
|
Outrigger kev pab them nqi |
1.7m x 1.7m |
1.7m x 1.7m |
1.6m x 1.6m |
1.7m x 1.7m |
1.9m x1.7m |
2.3m*1.9m |
|
Qhov hnyav |
||||||
|
AC |
300 kg |
320kg ua |
345kg ua |
365kg ua |
3 85kg |
4 60kg |
|
DC |
335kg ua |
355kg ua |
380kg ua |
400 kg |
420kg ua |
495kg ua |
|
Hwj chim |
||||||
|
AC |
380V/220V/110V |
380V/220V/110V |
380V/220V/110V |
380V/220V/110V |
380V/220V/110V |
380V/220V/110V |
|
AC Tsav |
0.75KW |
0.75KW |
0.75KW |
0.75KW |
0.75KW |
0.75KW |
|
DC |
12V |
12V |
12V |
12V |
12V |
12V |
|
DC lub cev muaj zog |
1.5 KW TSI |
1.5 KW TSI |
1.5 KW TSI |
1.5 KW TSI |
1.5 KW TSI |
1.5 KW TSI |
|
Charger |
12V/15A |
12V/15A |
12V/15A |
12V/15A |
12V/15A |
12V/15A |
Feature
1. Cov khoom siv mast yog ua los ntawm high-strength aviation txhuas los xyuas kom meej qhov kev nyab xeeb ntawm cov neeg ua haujlwm.
2. Tus kheej-tsim ib qho tsim-hauv zawv zawg thaiv yog siv nruab nrab ntawm txhua lub mast, kom qhov sib txawv ntawm cov masts me me, thiab nws khiav thaum lifting ntau ruaj khov thiab txhim khu kev qha, zoo dua li cov qauv kev ywj pheej ntawm kev txhawb nqa log;
3. Cov plaub-log dov chassis tau txais los ntawm qhov chaw, uas tuaj yeem taug kev yooj yim txawm nyob hauv cov ces kaum thiab nqaim thiab nyuaj.
4. Lub guardrail tau txais kev txhim kho nqa, thiab muaj cov zawv zawg ntawm cov guardrails, uas yooj yim rau cov neeg ua haujlwm nce thiab tawm.
5. Muaj tus ntsuj plig theem ntawm lub chassis kom yooj yim xyuas kom lub tshuab nyob rau hauv txoj hauj lwm kab rov tav. Suction khob hom leveling ob txhais ceg nrog qib qhia yog ib txwm platform muab cov khoom ruaj khov thiab ruaj khov hauv av, txawm nyob rau hauv av me ntsis;
6. Txais American Curtis dual tswj hloov, lub platform tuaj yeem ua haujlwm ntawm nws tus kheej nce thiab nqis
7. Muaj qhov hloov pauv thaum muaj xwm txheej ceev ntawm lub platform los tiv thaiv cov khoom siv tsis ua haujlwm thiab ua kom muaj kev nyab xeeb ntawm cov neeg ua haujlwm
8. Muaj cov cuab yeej txo qis thaum muaj xwm txheej ceev hauv qab lub platform, txawm tias lub platform poob lub zog yuam kev, nws tuaj yeem ua kom lub platform qis qis thiab txo tus neeg teb xov tooj kev txhawj xeeb ntawm lub neej yav tom ntej, kev nyab xeeb siv.
9. Lub 100% pilot valve tswj qhov sib txawv, uas ntxiv txhim kho qhov sib txuam ntawm cov masts, kom sab laug thiab sab xis tuav ntawm lub siab-siab platform me me. Technology ua tau raws li EU CE cov qauv
Cov teeb meem uas yuav tsum tau them sai sai rau hauv kev nyab xeeb ntawm kev siv aluminium alloy nqa
Tej zaum yuav muaj qee qhov kev huam yuaj thaum siv lub tshuab nqa aluminium alloy. Tsuas yog los ntawm kev ceev faj peb tuaj yeem tiv thaiv cov xwm txheej no kom tsis txhob tshwm sim. Nyob rau hauv tus txheej txheem ntawm kev siv aluminium alloy elevator, peb yuav tsum nco ntsoov xyuas seb qhov kev tiv thaiv ntawm aluminium alloy elevator ua haujlwm li cas, thiab nrhiav qhov teeb meem thiab daws nws raws sijhawm.
